Robot Size (W)×(H)×(D): 5000mm×360mm×330mm (The Length can be customized)
The product meets the cleaning needs of centralized large-area PV panels. Integrating multi-platform data, it can achieve unmanned cleaning, automatically clean photovoltaic modules, start work on time, and return to the parking stand after cleaning is completed. It relies on its own PV panels to charge the battery without the need for power from the power station. The high protection level design can adapt to various harsh scenarios, and the comprehensive fault detection and modular design enables easy maintenance.
| Light-weight design | Aluminum alloy and independently developed light-weight materials are used, which ensure lighter weight and higher strength of the machine body; without giving additional pressure and load on the PV panels, it helps extend the service life of solar panels and reduce the maintenance cost. |
| Super-high compatibility |
With dual-axis self-adapting rotation, inspection and calibration functions, complicated scenarios can be adapted. For different types of PV panels, postures and positions can be adjusted flexibly without worrying about the compatibility issue.
|
| One-click group control function | Equipped with the background management for both the computer and mobile APP terminal, with one-click group control function, weather monitoring and automatic cleaning function. |
| Solar panel specific roller brush+high-speed DC motor |
The rolling brush adopts a soft PBT brush, which has no damage to the photovoltaic panel, strong cleanliness, low temperature resistance, corrosion resistance, and long service life, efficient cleaning of photovoltaic panels with high rotational speed without damage.
|
| Walking correction function |
It has vertical walking correction function (relative to the side of the solar panel), and the inclination angle is not more than 3 degrees when walking; It has horizontal adaptive walking function, and can connect the upper and lower bridges through the unit interval with a slope difference of not less than 25 degrees. |
Product background display
SPECIFICATION
Version: Lingguang G1
Size: 5000*600*400mm
(The Length can be customized)
Weight: 48~80KG
Working slope: 0~45°
Vertical drop: 5cm
Overcome obstacles: 5cm
Speed of travel: ≤15m/min
Cleaning efficiency: 99%
Range: one-way range of 1.8 kilometers
Rated power: 250W
Mode of travel: Electric machine+Road wheel
Operating ambient temperature: -40℃~65℃
Power supply: Self-powered of Solar +Built-in battery(standard 48V 15AH)
Control mode: Mobile Phone APP / Web / Cloud Platform
Power-off protection: Low battery reminder
Application scenario: Centralized solar panel power station
Cleaning method: Dry cleaning
Waterproofing grade: IP65
Cleaning components: Yes
Camera: Yes(optional)
Engineered for Non-Standard PV Installations
The X‑Human G1 is specifically developed for solar arrays that do not conform to standard grid patterns. Whether you're dealing with uneven rooftops, multi-angled panel rows, or space-limited structures, the G1 adapts with ease. As a powerful and compact solar panel cleaning robot, it navigates tight gaps, varied elevations, and non-linear arrays to deliver deep, reliable cleaning. This flexibility makes it the preferred choice for site operators seeking customized solar panel cleaning solutions without compromising performance.
Built by Premier Solar Panel Cleaning Robot Manufacturers
Developed by X‑Human—recognized among the top solar panel cleaning robot manufacturers—the G1 incorporates industrial-grade drive wheels, anti-slip tracks, and a smart brush control system. These features work together to keep the robot stable, even on steep slopes or slick surfaces. Sensors embedded in the unit detect the edges of panels in real time, ensuring no overshoot or accidental drops. This level of safety and engineering precision is what makes the G1 not just a machine, but a professional-grade solar panel cleaning machine trusted by engineers worldwide.
Designed for High-Speed Cleaning with Minimal Water
Cleaning large solar arrays traditionally requires significant water and labor. The G1 solves both problems. As a high-output solar panel cleaning equipment system, it can clean up to 800 m² per hour while using as little as 0.2 L of water per square meter. Its soft-brush roller technology removes accumulated dust, bird droppings, and pollen without scratching delicate coatings. Whether operating in dry mode for deserts or wet mode for humid zones, this solar panel cleaning robot ensures peak panel efficiency with minimal environmental impact.
Adaptable Across Global Solar Projects
From commercial rooftops in Tokyo to industrial-scale farms in North Africa, the G1 has been deployed in diverse climates and array types. It’s compact enough for narrow passages, durable enough for rugged terrain, and smart enough to detect surface irregularities in real-time. With a foldable frame, the G1 is easy to ship, assemble, and transport between locations—making it the most versatile solar panel cleaning solution for operators managing multiple sites. Its multilingual interface supports seamless use across global teams.
Product Advantages
1. Precision Cleaning for Customized Solar Installations
The G1 is not just a typical solar panel cleaning robot—it is uniquely engineered to accommodate complex, irregular, and multi-angled solar arrays. Whether your panels are split into tight zones, mounted on slanted rooftops, or surrounded by obstructions, the G1 automatically adjusts its motion and brush pressure for seamless navigation. As a standout in solar panel cleaning equipment, it delivers consistent results where other machines cannot, making it a go-to solution for operators managing architecturally complex installations.
2. High-Efficiency Output with Water-Saving Technology
Time and water are precious resources on large solar sites. That’s why the G1 is engineered to clean up to 800 square meters per hour while minimizing water use to as low as 0.2 liters per square meter. It supports dry-cleaning mode for dust-prone areas and wet-cleaning for regions where pollen or pollution residue is common. These features allow solar farms to maintain high energy yields with minimal ecological impact. It is one of the most environmentally responsible solar panel cleaning machines on the market, ideal for operators seeking sustainable solar panel cleaning solutions.
3. Designed by Elite Solar Panel Cleaning Robot Manufacturers
Built by one of the top solar panel cleaning robot manufacturers in the industry, the G1 is rigorously tested for performance, weather resistance, and safety. It features corrosion-resistant housing, sealed control electronics, and heat-tolerant materials. Every unit is built to withstand prolonged exposure to UV radiation, moisture, and sand—making it ideal for desert, coastal, or high-humidity regions. This durability ensures that the robot delivers long-lasting performance as a dependable solar panel cleaning machine in critical power generation environments.
4. Intelligent Safety and Automation
The G1 incorporates a suite of sensors and safety algorithms that detect panel edges, gaps, and mounting rails in real-time. It intelligently slows down on steep inclines, adjusts brush pressure to avoid wear on coating layers, and halts immediately upon detecting unexpected changes in terrain. These systems ensure smooth, damage-free cleaning cycles. When deployed as part of a larger solar panel cleaning solution, it minimizes both operational risk and human intervention—maximizing productivity and equipment lifespan.
5. Low Maintenance and Easy Deployment Across Sites
The G1’s modular design makes it fast to assemble, easy to clean, and simple to service. Brushes, batteries, and wheels can be replaced on-site with minimal tools and training. Compatible with multiple solar setups, this robot is frequently used across multiple facilities by just one operations team. It is a practical solar panel cleaning equipment investment for those managing several locations or third-party service contractors providing large-scale solar panel cleaning solutions across regions.
Usage Environments
The X‑Human G1 is specifically designed to excel in a wide variety of solar environments. For industrial rooftops with limited walkways, the G1’s slim profile and compact design allow it to maneuver around tight corners and sloped panels, offering thorough cleaning coverage even in constrained layouts. On large-scale solar farms—whether mounted on ground or elevated structures—the robot delivers consistent and rapid cleaning over long rows, reducing the downtime associated with manual cleaning cycles. In desert regions such as northern Africa or the Middle East, where dust accumulation is a constant challenge, the G1’s dry-cleaning capability ensures that panels remain clean with no water dependency. Likewise, in coastal and tropical zones like Southeast Asia or Brazil, its corrosion-resistant materials and water-efficient design make it ideal for cleaning high-humidity installations while protecting panel surfaces from mold and salt residue. Whether deployed on rooftops, carports, tracking systems, or hybrid structures, the G1 adapts to each unique site, making it a versatile and globally applicable solar panel cleaning solution.
Verified Customer Reviews
“We’ve deployed G1 across rooftop systems in Berlin. Its ability to handle elevation changes and tight corners makes it perfect.”
— Berlin, Germany
“Our 500 kW solar farm in Cape Town uses the G1 for weekly cleanings. It handles heat and dust without any faults.”
— Cape Town, South Africa
“It’s the only solar panel cleaning robot we trust on our complex roof in Osaka—effortless navigation, amazing results.”
— Osaka, Japan
“The G1 saves us water and time in our São Paulo plant. Very efficient, reliable, and easy to maintain.”
— São Paulo, Brazil
Don’t let dust limit your energy yield. Get the X‑Human G1—a fully adaptable solar panel cleaning robot delivering precision and efficiency across the toughest installations. Contact us now to schedule a trial or get a custom quote.
