X-Human K3 Facade Cleaning Robot

Designed for flat, smooth glass facades. K3 combines onboard water recycling and battery-powered cleaning in a two-person field setup. Check panel width, frames and site rigging before deployment.



Robot dimensions: 1377 × 1025 × 368 mm. Net weight: 73 kg.

  • X-Human K3 Facade Cleaning Robot
  • X-Human K3 Facade Cleaning Robot
  • X-Human K3 Facade Cleaning Robot
  • X-Human K3 Facade Cleaning Robot
  • X-Human K3 Facade Cleaning Robot
  • X-Human K3 Facade Cleaning Robot
  • X-Human K3 Facade Cleaning Robot

Description

K3: Built for Flat Glass Facades

The X-Human K3 is a battery-powered cleaning robot for flat, smooth glass facades. It combines brush cleaning, squeegeeing and onboard water recovery for building-cleaning contractors and facility teams.

What It Means on Site

  • Reuse cleaning water. Onboard recovery and filtration reduce freshwater consumption and runoff.
  • Work without a trailing power cable. An onboard battery supplies power during cleaning.
  • Plan a two-person setup. Our field setup uses two operators. Roof access, rigging and site safety arrangements remain part of the job.
  • Stay in control. Automatic and manual travel/cleaning modes support the operator's working plan.

Check Your Facade First

K3 is designed for flat, smooth glass. The current operating manual specifies a working width over 1,100 mm and surface height differences no greater than 5 mm. Check panel joints, frames, protrusions, roof anchors and access before selecting equipment. Curved or obstructed facades require a separate model assessment.

Key Specifications

Item K3 specification
Robot dimensions 1377 × 1025 × 368 mm
Net weight 73 kg
Onboard water tank 9 L, with used-water recovery
Battery 48 V / 50 Ah
Battery runtime Approximately 2–3 hours; varies with working conditions
Travel speed 0.2 m/s
Theoretical cleaning efficiency 720 m²/h; actual output depends on the facade, soil level and deployment
Operating temperature 5–55°C
Deployment height Confirm the rope configuration and site-specific rigging plan

Dimensions, weight, tank capacity and operating conditions follow the current K-3 V4.0 manual. Confirm the supplied configuration in your quotation.

Safety Features

K3 uses suction adhesion, safety-rope support and a self-locking mechanism on power loss. Trained operators must inspect the rope, anchors and equipment, manage the work area and follow the operating manual. Site weather limits must be assessed before work.

Questions Buyers Ask

Does K3 need external water and power lines while cleaning?

K3 carries its own water tank and battery. Plan battery charging, water replenishment and recovery arrangements as part of the working setup.

How many people are needed?

Our field setup uses two operators. The site plan must also cover safe access, rigging and public-area control.

Can it clean any glass building?

No. Flatness, panel width, joints, protrusions and anchoring conditions determine suitability. For framed or obstructed facades, ask us to compare other models.

How much water will it save?

The onboard system recovers and filters used cleaning water. Actual water demand depends on the surface condition and cleaning method; we do not quote a universal savings percentage.

What happens if power is lost?

The self-locking mechanism is designed to keep the robot supported on the safety rope. Correct installation, rope condition and anchor checks are essential.

What should I send for a recommendation and quotation?

Please share your project country, building height, facade photos, panel dimensions and cleaning purpose. Let us know whether you are buying for cleaning services, your own facilities or resale.

Discuss Your Project

Request a K3 application review, email info@x-humanbot.com, or contact us on WhatsApp: +86 173 2209 6185.
